305DEEP HOLE DRILLING%u00bd%u0009Special Request Form Deep DrillingRequested Information Form for Deep Hole Drill Design Company name Telephone no.Address DateContact person Customer no.WorkpieceProduct name: Hole diameter:Hole depth:No. of holes: Tolerance (of hole):Surface finish (Rz, Ra...): Deviation (mm/100): Straightness (mm/100):MaterialMaterial (DIN, AISI, JIS...):Hardness (HB, HS, HRC...):Condition: o Quenched o Tempered o Cast o Annealedo OtherMachineMachine supplier name:Machine type/model: o NC lathe o Machining center o OtherRigidity: o Good o Normal o PoorSpindle power (kW):Tool and/or workpiece rotation (TR/WR): o Tool and workpiece o Rotating workpiece (WR) o Rotating tool (TR)Type of CoolantWater based: o Soluble o Emulsion %Oil based: o Coolant Pressure (bar): Coolant Volume (L/min):Tool Drill HeadDrill diameter: (mm/inch)Thread: o Inner o Outer o BrazedIndexable: o Adjustable o Direct mount Coating: o Coated o Uncoatedo Solid drilling o Counterboring Pre-drilled hole size: (mm/inch)Bottom finishing: o Full ball R o Flat bottom R o Corner R o OtherTrepanning: o Y o NTube outer diameter: (mm/inch) Core size diameter: (mm/inch)Please fill in and return to your ISCAR representative.
