306 ISCAR DEEP HOLE DRILLINGRequested Information Form for Deep Hole Drill Design (Continued)TubeOutside diameter: (mm/inch) Total Length: (mm/inch)Internal Thread:External Thread: 4 o Starts 2 o Starts 1 o StartsTube Thread: 1 o End o Both endsInner Tube Length: (mm/inch)Inner Tube Slit: 1 o End o Both endsDrilling System & Boring Conditionso Single Tube System: o Blind Hole Drilling o Double Tube Systemo Cross Hole Drilling: o Through Hole DrillingPlease Sketch Your Drilling ApplicationGeneral Production InformationQuantity of parts per year:Grade, tool life, etc.:Perfomance expectation: Vc= m/min N= RPM F= mm/min f= mm/revCutting data:Description of present system in use:Please fill in and return to your ISCAR representative.
